Lenovo Legion 5 15AHP10 (Eclipse Black)

The Lenovo Legion 5 15AHP10 is an AI-powered gaming laptop built for next-generation performance. With cutting-edge AMD Ryzen processing, NVIDIA RTX graphics, and a stunning OLED display, it delivers immersive visuals and intelligent gaming optimization in a sleek Eclipse Black design.

Key Specifications
Processor: AMD Ryzen™ 7 260 (8C / 16T, up to 5.1GHz)
Memory: 24GB DDR5-5600 (expandable up to 32GB)
Storage: 512GB PCIe 4.0 NVMe SSD
Graphics: NVIDIA® GeForce RTX™ 5060 8GB GDDR7
Screen Size: 15.1″ WQXGA (2560 × 1600) OLED, 165Hz
Operating System: Windows 11 Home
Software: Office Home 2024 + Lenovo AI Now

Detailed Specifications
Performance
Processor: AMD Ryzen™ 7 260 (8 cores / 16 threads, 3.8GHz base, 5.1GHz boost, 8MB L2 / 16MB L3 cache)
AI Features: Integrated AMD Ryzen™ AI NPU (up to 16 TOPS), AI Chip LA1
Graphics: NVIDIA® GeForce RTX™ 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 115W, 572 AI TOPS
Memory: 1× 24GB DDR5-5600 SODIMM, dual-channel capable, max 32GB
Storage: 512GB M.2 2242 PCIe 4.0 NVMe SSD, expandable with up to 2× M.2 SSDs (up to 1TB each)
Battery: 80Wh
Power Adapter: 245W Slim Tip (3-pin)
Display
Panel: 15.1″ WQXGA (2560 × 1600) OLED
Brightness: 1000 nits peak / 500 nits typical
Color Accuracy: 100% DCI-P3, factory calibrated
Refresh Rate: 165Hz
Features: Dolby Vision®, DisplayHDR™ True Black 600, 90% screen-to-body ratio
Design
Keyboard: 24-zone RGB backlit, English
Touchpad: Buttonless Mylar® multi-touch, Precision TouchPad support (75 × 120 mm)
Dimensions: 344.9 × 255.35 × 19.95–21.54 mm
Weight: Starting at 1.9kg (4.19 lbs)
Color: Eclipse Black
Materials: Aluminium top, PC-ABS bottom with 15% talc, anodized sandblasted finish
Connectivity
Wireless: Wi-Fi 7 (802.11be 2×2), Bluetooth 5.4
Ethernet: RJ-45 (100/1000M)
Ports:
2× USB-A (USB 3.2 Gen 1, 5Gbps)
1× USB-A (USB 3.2 Gen 1, Always On)
1× USB-C (USB 3.2 Gen 2, 10Gbps, PD 65–100W, DisplayPort 2.1)
1× USB-C (USB4, 40Gbps, DP 1.4)
1× HDMI 2.1 (up to 8K/60Hz)
1× Headphone/mic combo (3.5mm)
1× Ethernet (RJ-45)
1× Power connector
Audio & Camera
Speakers: Stereo 2W ×2, Harman audio, optimized with Nahimic
Microphone: Dual array
Camera: 5.0MP with E-shutter
Audio Chip: Realtek® ALC3287 codec
Software
Operating System: Windows 11 Home Single Language (English)
Bundled Software: Office Home 2024, Lenovo AI Now
Security & Certifications
Security: Firmware TPM 2.0, E-shutter camera privacy
Certifications: ENERGY STAR® 9.0, EPEAT® Gold, TÜV Rheinland® Low Blue Light
Warranty & Support
Base Warranty: 1-year Courier or Carry-in
Upgrade Included: 3-year Legion Ultimate Support

Why Choose the Lenovo Legion 5 15AHP10
AI-powered gaming: Integrated AMD Ryzen AI and NVIDIA RTX 5060 with AI acceleration.
Immersive OLED display: 15.1″ WQXGA panel with Dolby Vision and HDR True Black 600.
Future-ready connectivity: Wi-Fi 7, USB4, HDMI 2.1, and advanced docking support.
Premium design: Lightweight aluminium build with Eclipse Black finish and RGB keyboard.
Optimized audio & visuals: Harman speakers with Nahimic and factory-calibrated OLED for true-to-life colors.
